TPU Hot Melt Film Adhesive Superior Flexibility and Elasticity
| Lugar de origen | Porcelana |
| Nombre de la marca | JCC |
| Certificación | Oeko-tex Certificate, ISO, ZDHC |
| Número de modelo | JCC-TPU F601, JCC-TPU F6203 |
| Documento | Hot melt adhesive film.pdf |
TPU hot melt adhesive film
,flexible hot melt adhesive film
,elastic hot melt adhesive film
TPU Hot Melt Film Adhesive is a high-performance bonding solution made from thermoplastic polyurethane (TPU) base material. Available in two variants: with backing paper and without backing paper.
This adhesive film demonstrates exceptional elasticity and flexibility, with superior bonding to natural/synthetic fibers (cotton, polyester, nylon), leather, foam, plastics (PET, PVC), and other materials. It is environmentally friendly and safe, containing no solvents and featuring low VOC emissions.
| Type | Release Substrate | Melting Range (°C) | Suggested Press Temperature (°C) | Application Area |
|---|---|---|---|---|
| F601 | Release Paper | 90-120 | 120-140 | Clothing |
| F603 | Release Paper | 105-130 | 120-150 | Clothing/Shoe/Cleaning supplies |
| F6201 | PE blue film | 90-130 | 120-140 | Clothing/Bags/Shoe |
| F6203 | PE blue film | 105-145 | 130-150 | Reflective heat lamination/Heat transfer film |
| F6202 | PE blue film | 42-60 | 115-130 | Clothing/Bags/Shoe/Automobile sun visor |
| F6205 | PE blue film | 120-160 | 150-170 | Reflective heat lamination/Heat transfer film - Industrial washing |
| F6203FR | PE blue film | 80-160 | 160-170 | Reflective heat lamination/Heat transfer film |
The dual configuration enhances operational flexibility:
- Release-paper-backed variants facilitate pre-cutting, manual handling, and storage without adhesive contamination.
- Release-paper-free options optimize throughput in roll-to-roll automated systems, eliminating release paper disposal costs.
Key performance benefits include:
- Superior bond performance: Peel strength up to 8N/25mm (tested on PET substrates) for durable lamination.
- Broad environmental resistance: Temperature tolerance from -40°C to 120°C, plus resistance to humidity, chemicals, and UV aging.
- Sustainability compliance: Low VOC emissions, aligning with EU REACH and US EPA standards for indoor air quality.
| Dimension | Value Proposition | Typical Application Support |
|---|---|---|
| Environmental | Solvent-free, zero-VOC, OEKO-TEX/REACH compliant | Apparel, children's products, sun visors |
| Efficiency | 10-15 second rapid heat-pressing, compatible with continuous/intermittent production | Footwear assembly lines, clothing customization |
| Performance | Temperature resistance (-40°C-80°C), water/wash resistance, bend resistance | Automotive sun visors, sports shoes, cleaning supplies |
- Apparel Lamination & Decoration: Heat-transferring film, bonding shell fabric with barrier fabric of down jackets, stretch underwear.
- Bag Structural Reinforcement: Lamination of backpack fabrics with linings, bonding of luggage wear-resistant layers.
- Other Applications: Shoes materials, cleaning supplies, reflective materials, car sun visors.
A: TPU (thermoplastic polyurethane) hot-melt film is a highly elastic and flexible adhesive commonly used for bonding fabrics, leather, foam, and plastics. Its film form ensures easy handling and even application, bonding quickly upon heating and solidifying upon cooling.
A: Yes. Our TPU hot-melt adhesive films offer excellent water and weather resistance, making them suitable for washable fabrics and outdoor applications. Some products are dry-clean and UV-resistant.
A: Absolutely. TPU hot-melt film is compatible with various automated heat pressing, laminating, and rolling equipment, making it ideal for high-volume, continuous production environments.
